Auto Punching And Connecting Ribbon Machine

Automatic box punching machine

Fixed voltage: 220V

Required air pressure: 0.6MPa

Running speed: 23-28pcs/min

Maximum dimension of paper box: 250*300*80mm

Minimum dimension of paper box: 45*45*20mm

Total power of equipment: 2.5KW

Total weight: 200KG

Equipment size: 1260*710*1450mm

Function: Suitable for punching holes in 3D boxes, ribbon holes, nail holes, waste disposal, etc. This machine is a fully servo positioning punching machine that achieves precision and reliability, and can be used alonely or on line.

Automatic box connecting ribbon machine

Fixed voltage: 220V

Required air pressure: 0.6MPa

Ribbon width: 5-20mm

Ribbon length (exposed): 10-60mm

Ribbon sticker box length: 7-20mm

Board thickness: unlimited

Cardboard width: 30-500mm

Cardboard length: unlimited

Maximum dimension of paper box: 450*400*120mm

Minimum dimension of paper box: 50*50*15mm

Total power of equipment: 1.5KW

Total weight: 200KG

Equipment size: 1240*620*1650mm

Function: Suitable for wine boxes, jewelry boxes, mooncake boxes, makeup boxes, luxury boxes, watch boxes, and other products. Ribbon has a wide range of applications, including polyester, silk and satin ribbons. Snow gauze tape can be used.
