Automatic box punching machine
Fixed voltage: 220V
Required air pressure: 0.6MPa
Running speed: 23-28pcs/min
Maximum dimension of paper box: 250*300*80mm
Minimum dimension of paper box: 45*45*20mm
Total power of equipment: 2.5KW
Total weight: 200KG
Equipment size: 1260*710*1450mm
Function: Suitable for punching holes in 3D boxes, ribbon holes, nail holes, waste disposal, etc. This machine is a fully servo positioning punching machine that achieves precision and reliability, and can be used alonely or on line.
Automatic box connecting ribbon machine
Fixed voltage: 220V
Required air pressure: 0.6MPa
Ribbon width: 5-20mm
Ribbon length (exposed): 10-60mm
Ribbon sticker box length: 7-20mm
Board thickness: unlimited
Cardboard width: 30-500mm
Cardboard length: unlimited
Maximum dimension of paper box: 450*400*120mm
Minimum dimension of paper box: 50*50*15mm
Total power of equipment: 1.5KW
Total weight: 200KG
Equipment size: 1240*620*1650mm
Function: Suitable for wine boxes, jewelry boxes, mooncake boxes, makeup boxes, luxury boxes, watch boxes, and other products. Ribbon has a wide range of applications, including polyester, silk and satin ribbons. Snow gauze tape can be used.
Automatic box punching machine
Fixed voltage: 220V
Required air pressure: 0.6MPa
Running speed: 23-28pcs/min
Maximum dimension of paper box: 250*300*80mm
Minimum dimension of paper box: 45*45*20mm
Total power of equipment: 2.5KW
Total weight: 200KG
Equipment size: 1260*710*1450mm
Function: Suitable for punching holes in 3D boxes, ribbon holes, nail holes, waste disposal, etc. This machine is a fully servo positioning punching machine that achieves precision and reliability, and can be used alonely or on line.
Automatic box connecting ribbon machine
Fixed voltage: 220V
Required air pressure: 0.6MPa
Ribbon width: 5-20mm
Ribbon length (exposed): 10-60mm
Ribbon sticker box length: 7-20mm
Board thickness: unlimited
Cardboard width: 30-500mm
Cardboard length: unlimited
Maximum dimension of paper box: 450*400*120mm
Minimum dimension of paper box: 50*50*15mm
Total power of equipment: 1.5KW
Total weight: 200KG
Equipment size: 1240*620*1650mm
Function: Suitable for wine boxes, jewelry boxes, mooncake boxes, makeup boxes, luxury boxes, watch boxes, and other products. Ribbon has a wide range of applications, including polyester, silk and satin ribbons. Snow gauze tape can be used.
